cold_banner

 Cold Store Panels

coldstore

EIP&#8217;s Cold Store Panels (CSP) are designed for temperature-controlled environments, suitable for internal walls, ceilings, partitions, and external roofs. The panels feature excellent insulation and durability, integrated waterproofing, and a design that allows for quick and efficient installation. This guarantees reliable performance across diverse cold storage applications.

cold_pic

Cold Store Panels

<table dir="ltr" border="1" cellspacing="0" cellpadding="0" data-sheets-root="1" data-sheets-baot="1">
<colgroup>
<col width="112" />
<col width="60" />
<col width="60" />
<col width="60" />
<col width="60" />
<col width="60" /> </colgroup>
<colgroup>
<col width="60" /></colgroup>
<colgroup>
<col width="60" />
<col width="60" /></colgroup>
<tbody>
<tr>
<td>Core Thickness (mm)</td>
<td>55</td>
<td>80</td>
<td>100</td>
<td>120</td>
<td>140</td>
<td>150</td>
<td>170</td>
<td>200</td>
</tr>
<tr>
<td>Weight (kg/m2)1</td>
<td>10.4</td>
<td>11.4</td>
<td>12.2</td>
<td>13</td>
<td>13.8</td>
<td>14.2</td>
<td>15</td>
<td>16.2</td>
</tr>
<tr>
<td>U-value – PIR (W/m²K)2</td>
<td>0.38</td>
<td>0.26</td>
<td>0.21</td>
<td>0.17</td>
<td>0.15</td>
<td>0.14</td>
<td>0.12</td>
<td>0.1</td>
</tr>
</tbody>
</table>

Thermal Performance & Weight

With a double tongue-and-groove joint, these panels interlock together perfectly, delivering airtight, fire-rated performance you can trust.
This system eliminates thermal bridging and provides superior insulation integrity. The extended steel edges within the joint add structural strength and delay flame penetration, enhancing fire protection and overall durability.

colstore-panels

CSP Joint System

EIP’s Cold Store Panels (CSP) are available in lengths ranging from 2000 mm to 18000 mm.
The span table is based on panels with the standard 0.50 mm steel thickness for both internal and external facers.
When used as self-standing partition panels, the span guide indicates the maximum CSP panel lengths achievable for different thicknesses.
System Width: 1110 mm (effective coverage width)
Profile Options: Low Rib, Flat, Groove, Microline, and Microwave

thermal

Wall and Ceiling Span Guide

Panel Features

Cold Store Panels Installation

<table width="640">
<colgroup>
<col span="9" width="64" /></colgroup>
<tbody>
<tr>
<td class="xl492" width="128" height="49">Panel Thickness (mm)</td>
<td class="xl370" align="right" width="64">55</td>
<td class="xl370" align="right" width="64">80</td>
<td class="xl370" align="right" width="64">100</td>
<td class="xl370" align="right" width="64">120</td>
<td class="xl370" align="right" width="64">140</td>
<td class="xl370" align="right" width="64">150</td>
<td class="xl370" align="right" width="64">170</td>
<td class="xl371" align="right" width="64">200</td>
</tr>
<tr>
<td class="xl494" colspan="9" width="128" height="40">Temperature Differential (TD)</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">10 ºC</td>
<td class="xl374" align="right">3.78</td>
<td class="xl375" align="right">2.6</td>
<td class="xl375" align="right">2.08</td>
<td class="xl375" align="right">1.73</td>
<td class="xl375" align="right">1.49</td>
<td class="xl375" align="right">1.39</td>
<td class="xl375" align="right">1.22</td>
<td class="xl375" align="right">1.04</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">15 ºC</td>
<td class="xl376" align="right">5.67</td>
<td class="xl377" align="right">3.9</td>
<td class="xl377" align="right">3.12</td>
<td class="xl377" align="right">2.6</td>
<td class="xl377" align="right">2.23</td>
<td class="xl377" align="right">2.08</td>
<td class="xl377" align="right">1.84</td>
<td class="xl377" align="right">1.56</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">20 ºC</td>
<td class="xl376" align="right">7.56</td>
<td class="xl377" align="right">5.2</td>
<td class="xl377" align="right">4.16</td>
<td class="xl377" align="right">3.47</td>
<td class="xl377" align="right">2.97</td>
<td class="xl377" align="right">2.77</td>
<td class="xl377" align="right">2.45</td>
<td class="xl377" align="right">2.08</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">25 ºC</td>
<td class="highlighted" align="right">9.45</td>
<td class="xl377" align="right">6.5</td>
<td class="xl377" align="right">5.2</td>
<td class="xl377" align="right">4.33</td>
<td class="xl377" align="right">3.71</td>
<td class="xl377" align="right">3.47</td>
<td class="xl377" align="right">3.06</td>
<td class="xl377" align="right">2.6</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">30 ºC</td>
<td class="xl376" align="right">11.35</td>
<td class="xl377" align="right">7.8</td>
<td class="xl377" align="right">6.24</td>
<td class="xl377" align="right">5.2</td>
<td class="xl377" align="right">4.46</td>
<td class="xl377" align="right">4.16</td>
<td class="xl377" align="right">3.67</td>
<td class="xl377" align="right">3.12</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">35 ºC</td>
<td class="xl376" align="right">13.24</td>
<td class="highlighted" align="right">9.1</td>
<td class="xl377" align="right">7.28</td>
<td class="xl377" align="right">6.07</td>
<td class="xl377" align="right">5.2</td>
<td class="xl377" align="right">4.85</td>
<td class="xl377" align="right">4.28</td>
<td class="xl377" align="right">3.64</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">40 ºC</td>
<td class="xl376" align="right">15.13</td>
<td class="xl377" align="right">10.4</td>
<td class="xl377" align="right">8.32</td>
<td class="xl377" align="right">6.93</td>
<td class="xl377" align="right">5.94</td>
<td class="xl377" align="right">5.55</td>
<td class="xl377" align="right">4.89</td>
<td class="xl377" align="right">4.16</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">45 ºC</td>
<td class="xl376" align="right">17.02</td>
<td class="xl377" align="right">11.7</td>
<td class="highlighted" align="right">9.36</td>
<td class="xl377" align="right">7.8</td>
<td class="xl377" align="right">6.69</td>
<td class="xl377" align="right">6.24</td>
<td class="xl377" align="right">5.51</td>
<td class="xl377" align="right">4.68</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">50 ºC</td>
<td class="xl376" align="right">18.91</td>
<td class="xl377" align="right">13</td>
<td class="xl377" align="right">10.4</td>
<td class="xl377" align="right">8.67</td>
<td class="xl377" align="right">7.43</td>
<td class="xl377" align="right">6.93</td>
<td class="xl377" align="right">6.12</td>
<td class="xl377" align="right">5.2</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">55 ºC</td>
<td class="xl376" align="right">20.8</td>
<td class="xl377" align="right">14.3</td>
<td class="xl377" align="right">11.44</td>
<td class="highlighted" align="right">9.53</td>
<td class="xl377" align="right">8.17</td>
<td class="xl377" align="right">7.63</td>
<td class="xl377" align="right">6.73</td>
<td class="xl377" align="right">5.72</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">60 ºC</td>
<td class="xl376" align="right">22.69</td>
<td class="xl377" align="right">15.6</td>
<td class="xl377" align="right">12.48</td>
<td class="xl377" align="right">10.4</td>
<td class="xl377" align="right">8.91</td>
<td class="xl377" align="right">8.32</td>
<td class="xl377" align="right">7.34</td>
<td class="xl377" align="right">6.24</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">65 ºC</td>
<td class="xl376" align="right">24.58</td>
<td class="xl377" align="right">16.9</td>
<td class="xl377" align="right">13.52</td>
<td class="xl377" align="right">11.27</td>
<td class="highlighted" align="right">9.66</td>
<td class="xl377" align="right">9.01</td>
<td class="xl377" align="right">7.95</td>
<td class="xl377" align="right">6.76</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">70 ºC</td>
<td class="xl376" align="right">26.47</td>
<td class="xl377" align="right">18.2</td>
<td class="xl377" align="right">14.56</td>
<td class="xl377" align="right">12.13</td>
<td class="xl377" align="right">10.4</td>
<td class="highlighted" align="right">9.71</td>
<td class="xl377" align="right">8.56</td>
<td class="xl377" align="right">7.28</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">75 ºC</td>
<td class="xl376" align="right">28.36</td>
<td class="xl377" align="right">19.5</td>
<td class="xl377" align="right">15.6</td>
<td class="xl377" align="right">13</td>
<td class="xl377" align="right">11.14</td>
<td class="xl377" align="right">10.4</td>
<td class="xl377" align="right">9.18</td>
<td class="xl377" align="right">7.8</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">80 ºC</td>
<td class="xl376" align="right">30.25</td>
<td class="xl377" align="right">20.8</td>
<td class="xl377" align="right">16.64</td>
<td class="xl377" align="right">13.87</td>
<td class="xl377" align="right">11.89</td>
<td class="xl377" align="right">11.09</td>
<td class="highlighted" align="right">9.79</td>
<td class="xl377" align="right">8.32</td>
</tr>
<tr>
<td class="xl372" align="right" height="21">85 ºC</td>
<td class="xl376" align="right">32.15</td>
<td class="xl377" align="right">22.1</td>
<td class="xl377" align="right">17.68</td>
<td class="xl377" align="right">14.73</td>
<td class="xl377" align="right">12.63</td>
<td class="xl377" align="right">11.79</td>
<td class="xl377" align="right">10.4</td>
<td class="highlighted" align="right">8.84</td>
</tr>
</tbody>
</table>
Thermal conductivity factor for PIR foam λ= 0.0208 W/mK
Minimum value for heat gain in a coldstore = 10 W/m2
TD = Temperature difference between inside and outside of coldstore.

Heat Transmission Table

rectangle-3463567-1

Rectangle 3463567 (1)

industrial-doors-2-2

industrial-doors-2

2018-1

colstore-panels-2

ofi-2

2022

2018

Cold Store Panels Gallery

Discover high-performance cold store panels engineered for optimal thermal control and energy efficiency.

Cold Store Panels | Reliable Insulation by Emirates Panel

roof_banner

Roof & Wall Panels

roof-and-wall

EIP&#8217;s Roof and Wall Panels deliver superior insulation, strength, and flexibility. Designed for warehouses, factories, cold stores, and modern industrial facilities, our panels are engineered to perform in the toughest climates.
EIP panels combine modern aesthetics with technical performance. Featuring multiple profiles and thicknesses, our range suits industrial, commercial, and architectural applications, ensuring energy savings, fire resistance, and long service life.

image-428-3-2

image 428 (3)

The TRP 40/333 is a trapezoidal roof panel, through-fixed on the side-lap joints. The name ‘40/333’ indicates the rib height (40mm) and valley width (333mm).
The 40mm-high ribs provide superior strength and water resistance, withstanding extreme weather while maintaining air-tight performance.
This versatile cladding solution is suitable for all buildings with roof slopes as low as 2.85<code>o</code> (5.0%)1. For specific cases, EIP’s technical team can advise on the ideal slope based on building length.
All EIP TRP panels can be installed as roof or wall fixtures.
1 Contact EIP&#8217;s technical team for assistance with selecting the correct design for your required slope

40-333

TRP: Trapezoid Roof Panel 40/333

The TRP 40/333 Flex is a lighter variant of the TRP 40/333, with the same trapezoid form, but featuring
aluminium foil as the inner sheet of the panel.
This panel is through-fixed on the side lap joints, and is an all-rounder roof cladding suitable for use in all buildings with roof slopes not less than 5<code>o</code> (8.75%)1.
It is a functional and economic option to clad the roofs of buildings effectively.
1 Contact EIP&#8217;s technical team for assistance with selecting the correct design for your required slope

40-333-flex

TRP: Trapezoid Roof Panel 40/333 Flex

The TRP 45/150 is a trapezoidal roof panel, through-fixed on the side-lap joints.
The name &#8217;45/150&#8242; indicates the rib height (45mm) and valley width (150mm).
With taller ribs and a higher rib count, this panel offers greater spanning capability, superior strength, and effective water resistance &#8211; making it suitable for demanding roof applications.
It can be installed on buildings with slopes as low as 2.85<code>o</code> (5.0%)1. For special cases, consult EIP’s technical team for recommendations.
1 Contact EIP&#8217;s technical team for assistance with selecting the correct design for your required slope

45-150

TRP: Trapezoid Roof Panel 45/150

The HFW is an architectural wall panel with a hidden-fix joint system.
This system conceals the fasteners used to install the panels, providing a smooth, aesthetic look to a building&#8217;s facade.
It can be installed horizontally or vertically on any building with positive internal temperatures.
Preferred by architects, HFW panels can easily be cut and modified to meet diverse requirements while maintaining the aesthetic integrity of a facade.

HFW: Hidden-Fix Wall (Architectural)

The TFW is a double tongue-and-groove joint wall panel.
This standard panel is through-fixed onto structures. It can be installed horizontally or vertically on any type of building.
Thanks to its design, EIP&#8217;s TFW panel can be used as self-standing internal partition wall and as a suspended ceiling.

TFW: Through-Fix Wall & Partition

The SWP has an economic, cost-efficient design for low-rise buildings.
This panel features a slip-joint and is through-fixed onto a structure.
It can be installed horizontally or vertically, and is predominantly used in agricultural or modular prefabricated buildings.

SWP: Standard Wall Panel

Products

roof-and-wall-5

roof-and-wall-2

roof-and-wall-7

roof-and-wall-6

roof-and-wall-1

roof-and-wall-3

roof-and-wall-4

Roof & Wall Panels Gallery

Emirates Panel’s roof and wall panels provide superior durability, thermal insulation, and weather protection for all structures.

Roof & Wall Panels | Durable & Efficient Systems UAE

Roof &#038; Wall Panels

rectangle-7901-12

Rectangle 7901 (12)

Flashings & Accessories

flashing-and-accessories

EIP manufactures custom flashings and installation accessories in-house to ensure every project has a clean and uniform finish.
Our machinery allows us to produce flashings up to 6 meters in length and up to 1.5mm in thickness, with accurate angles and shapes to suit different design requirements.

flashing-and-accessories-8

 Our flashings are produced using the same material and finish as the panels to ensure a seamless color match for your installation.

Material Consistency

Our flashings are designed to match panel profiles and project specifications.

Custom Profiles

PVC covings for inner and outer corners are available for applications requiring easy cleaning and improved hygiene.

 Hygienic Options

Pre-cut and pre-assembled accessory packs can be provided to reduce on-site work and minimize material waste.

Ready-to-Install Kits

Benefits of EIP's Flashings & Accessories:

flashing-and-accessories-1

flashing-and-accessories-2

flashing-and-accessories-3

flashing-and-accessories-5

flashing-and-accessories-6

flashing-and-accessories-7

flashing-and-accessories-9

Flashings & Accessories Gallery

Enhance performance and finish with Emirates Panel’s flashings and accessories designed for precision and protection.

Flashings & Accessories | Finishing Components UAE

Flashings &#038; Accessories

rectangle-7901-11

Rectangle 7901 (11)

Industrial Doors

industrial-doors-9

industrial-doors

EIP offers a comprehensive range of industrial doors designed to meet the demanding needs of cold storage, industrial, and commercial environments.
Our solutions combine functionality, durability, and insulation performance for seamless operation across various applications, including:
• Hinged Doors
• Horizontal Sliding Doors (Manual &amp; Automatic)
• Vertical Sliding Doors (Automatic)
• Rapid Access Doors (for Chiller &amp; Freezer Applications)
• Stainless Steel Doors
• Swing Doors

image-428-5

image 428 (5)

Off-white RAL 9002 door leaves as standard (other RAL colours available upon request).

Standard Colour Options

Internal safety release for enhanced user safety.

Enhanced Safety

Heated door frame, wall frame, and floor threshold options for low-temperature and freezer applications.

Heated Frame Options

Available in multiple thicknesses: 100 mm for chiller applications, and 140 mm for freezer and blast freezer applications.

Multiple Thickness Configurations

Door Features

Building a Green Future With Every Panel

Global Leaders in High-Performance Insulated Panel Solutions

Our Product Range

Cold Store Panels

Roof & Wall Panels

Flashings & Accessories

Industrial Doors

Loading Points

Years of Industry Expertise

0

Annual Production Capacity

0

Product Certifications

0

Countries Served

0

Trusted by Top-Tier Clients Worldwide

EIP Fire Shield

Why Global Leaders Choose EIP

Certified Quality

Engineering Expertise

Customized Solutions

Sustainability

Comprehensive Support

Turnkey Solutions for Cooling

Sustainability And Innovation

Get in Touch
